5 T Electric Forklift 5M

Basic Info

Model No.: CPD50-5M

Product Description


WINGS CPD50-5M Electric Forklift Truck

5 Tons Loading Capacity & 5 meters Lifting Height


Feature

1. Small front overhang design and light mast weight improves the work stability and lower energy consumption.

2. Adopt large speed ratio drive axle box assembly to improve work efficiency, climbing ability, reduce energy consumption and noise.

3. Ergonomic anti-fatigue seat and steering wheel enable to be adjusted at multiple angles as needed.

4. Smart large screen LED instrument, good visibility, intuitive reading, friendly human-computer interface.


Optional Li-ion Battery

*Energy consumption is more than 30% lower than the regular electric forklift, greatly saving the charging cost

*Up to 10 years battery lifespan

*Enclosed design, free of maintemance

*Fast charging, full charge in 2hrs at the soonest

*Lithium iron phosphate battery, anti-fire and anti-explosion


electric forklift truck 5 tons


Main Specification

WINGS Electric Counterbalance Forklift

1.1

Manufacturer


WINGS

1.2

Model


CPD50

1.3

Power Type


Battery

1.4

Operation Type


Driving Style - Seat on

1.5

Rated Capacity

Q(kg)

4999

1.6

Load Center

C(mm)

500

1.8

Front Overhand

x(mm)

530

1.9

Wheelbase

y(mm)

2000

Weight

2.1

Service Weight(incl.battery)

kg

7100

Wheel

3.1

Wheel Types


Solid rubber tyre

3.2

Load Wheel

mm

21×8-9

3.3

Drive wheel

mm

250-15

3.5

Number of wheels,,front/rear(x=drive wheel)


2x/2

3.6

Wheel tread,drive side

b10(mm)

1225

3.7

Wheel tread,load side

b11(mm)

1025

Size

4.1

Mast tilting

α/β(°)

6/11

4.2

Mast closed height

h1(mm)

2180

4.3

Free lift height

h2(mm)

150

4.4

Lift height

h3(mm)

3000

4.5

Mast extended height with load-backrest

h4(mm)

4040

4.7

Overhead guard height

h6(mm)

2250

4.8

Seat height

h7(mm)

1230

4.19

Overall length

L1(mm)

4060

4.20

Length to fork face

L2(mm)

2990

4.21

Overall width

b1/b2(mm)

1470/1350

4.22

Fork size

l/e/s(mm)

1070/150/50

4.23

Installation level


3A

4.24

Fork carriage width

b3(mm)

1380

4.25

Fork outside width

b5(mm)

320~1320

4.31

Mast ground clearance

m1(mm)

120

4.32

Body ground clearance

m2(mm)

120

4.34

Aisle width for pallet 1000*1200

Ast(mm)

4490


Aisle width for pallet 800*1200

Ast(mm)

4690

4.35

Turning radius

Wa(mm)

2690

Function

5.1

Driving speed(load/unload)

km/h

12/13

5.2

Lifting speed(load/unload)

mm/s

200/220

5.3

Lowering speed(load/unload)

mm/s

270/290

5.5

Traction capacity(load/unload)(S2-5min)

N

15680

5.8

Max.Grade-ability(load/unload)(S2-5min)

%(tanθ )

15/15

5.10

Brake type


Mechanical hydraulic

Drive

6.1

Driving motor(S2-60min)

kw

AC16.6

6.2

Lifting motor(S3-15%)

kw

AC15

6.4

Battery voltage/capacity

V/Ah

80/630

6.5

Battery weight

kg

1690

6.6

Steering system


Hydraulic type

Other

7.1

Lithium battery configuration

V/Ah

80/525


EXCEPTIONAL MACHINERY

WINGS manufacture a wide range of Electric Forklift, vary from 0.8t Electric Forklift to 5 tons Electric Forklift. With highly customized lift height options to fit your pratical requirements and budget.


BEST-IN-CLASS WARRANTY

One year unlimited hours warranty of every forklift we manufacture, along with free spare parts supply and troubleshooting.


QUALITY PARTS & SERVICE

We’ll help keep your forklifts at peak performance with highly trained service professionals and reliable parts.
